DO Series
DO Series domed ribbed tubing plugs use exterior ribs to grip securely inside the tubing while providing a clean, finished appearance.
- Suitable as finishing plugs for metal furniture
- Domed design provides an attractive finish
- Exterior ribs support a secure fit inside the tube
- Helps shield against injury and impact
For more information or to order this part, contact us at +61 7 3277 2300
Additional information
| Material | Low-Density Polyethylene |
|---|---|
| Service Temperature | -70 – 79° C |
| Standard Colour | Black |
Part Sizes
Item Number | To Fit Tube Size OD (In) | Gauge (Wall Thickness) (In) |
DO-6 | 3/4 SQR Half – Moon Head | 14 – 20 Ga. (.083 – .035) |
DO-7 | 7/8 SQR Half – Moon Head | 14 – 20 Ga. (.083 – .035) |
DO-16 | 2 SQR Pyramid Head | 14 – 20 Ga. (.083 – .035) |
DO-16-1 | 2 SQR Pyramid Head | 10 – 14 Ga. (.134 – .083) |
